The main design feature of the Plant Trailer fabricated chassis is the 180 x 65 x 5mm C-Section Channelthat runs the full length of the Plant Trailer allowing the chassis toflex and move as it negotiates rough road terrain.
The C-Section fabricated chassis is made of laser cut, CNC folded, 350* grade, open chassis members allowing foreasy wash down and cleaning,with no enclosed areas where mud, sand and salt can get trapped and cause corrosion.
Fitted with CNC folded Checker Plate Mudguards, secure Spare Tyre Storage, 65mm Square Steel 95mm Drop Axles, Tie Down Points, Chain Slot Provision, and Powder Coated with a durable finish; thePlant Trailer is ready to be your versatile hauling machine for all your plant and equipment.
*350 grade is higher tensile steel. Box section is 300 grade and most C-Sections are 300.
Attachment Storage Options | Auger Points, Bucket Rests etc.
Centre Deck Panels for Rollers/Commercial Mowers etc.
Full Width Ramp
4.5T ATM Upgrade
Rear Toolbox for Straps
Bluetooth Brake Controller Kit
Hydraulic Override Brake Upgrade
Additional 1.12T Rated Tie-Down Points
Colour Upgrade
QLD Rego
2 - 2500 kg (5T) Load Sharing Leaf Spring Suspension Set
2 - 3000 kg (6T) 95mm Square Steel Drop Axles
4 - 12-inch Electric Drum Brakes
4 - 3000 kg (12T) UNIHUB Dual Row Taper Roller Bearings - Triple Lip Marine Seal with a Secondary O-Ring Seal incorporated into Dust Cap. (3 Year Manufacturers Warranty)
Twin Modular, removable suspension assemblies
5 - 16-inch Landcruiser Pattern 5 Stud Rims
5 - All Terrain 245/75 R16 Tyres
TRAILER RUNNING GEAR
TRAILER SIZE
OPTIONAL ACCESSORIES
FLEXIBLE YETDURABLE
The Plant Trailer is designed to haul a large variety of equipment and attachments to your next maintenance, construction or industrial location. With versatility at its core, this trailer is ready to become the transport solution your business needs. View our brochure for more information.
